Engine Type - Electric | 100Ah 36V Li-ion Battery |
power supply |
Gradeability | 28 % |
Cantilever-articulation range | 89 degrees |
Platform capacity | 500 lbs / 226.80 kg |
Platform capacity is limited | 500 lbs / 226.80 kg |
Slope Tolerance | 12 |
swing | 360 degrees |
Swing Type | Discontinuous |
Performance |
Machine height | 6 feet 6 inches. / 1.98 meters |
Machine length | 13 ft. 2 in. / 4.01 m |
Machine width | 2 feet 5 inches. / 0.74 meters |
Outrigger footprint length | 9 ft. 2 in. / 2.79 m |
Outrigger coverage width | 9 ft. 2 in. / 2.79 m |
Platform Dimension A | 4 feet 10 inches. / 1.47 meters |
Platform size B | 2 feet 6 inches. / 0.76 meters |
Track length | 4 feet 1 in. / 1.24 m |
Number of sizes |
Horizontal expansion | 21 ft. 7 in. / 6.58 m |
Working height | 50 feet / 15.24 meters |
Meet the specifications |
Ground bearing pressure - outriggers | 34.1 lbs/in² / 2.39 kg/cm² |
Machine weight | 4392 lbs / 1992.18 kg |
