Engine Type - Electric | 100Ah 48V Li-ion Battery |
power supply |
Gradeability | 28 % |
Outriggers or Stabilizers | yes |
Platform capacity | 500 lbs / 226.80 kg |
Slope Tolerance | 12 |
swing | 360 degrees |
Swing Type | Discontinuous |
Cantilever-articulation range | 89 degrees |
Performance |
Machine height | 6 feet 7 inches. / 1.99 meters |
Machine length | 14 ft. 10 in. / 4.52 m |
Machine width | 2 feet 7 inches. / 0.79 meters |
Outrigger footprint length | 10 ft. 5 in. / 3.18 m |
Outrigger coverage width | 10 ft. 5 in. / 3.18 m |
Platform Dimension A | 4 feet 10 inches. / 1.47 meters |
Platform size B | 2 feet 6 inches. / 0.76 meters |
Track length | 4 feet 1 in. / 1.24 m |
Number of sizes |
Horizontal expansion | 23 feet / 7.01 meters |
Platform height | 49 feet / 14.94 meters |
Meet the specifications |
Maximum ground pressure | 9.7 lbs/in² / 0.68 kg/cm² |
Ground bearing pressure - outriggers | 35.5 psi / 2.49 kg/cm2 |
Machine weight |
5071 lbs / 2300.17 kg |
