power supply | |
Engine Type - Electric | 100Ah 72V Li-ion |
Performance | |
Gradeability | 28 % |
Outriggers or Stabilizers | yes |
Platform capacity | 500 lbs / 226.80 kg |
Slope Tolerance | 15 |
swing | 360 degrees |
Swing Type | Discontinuous |
Cantilever-articulation range | 89 degrees |
Number of sizes | |
Machine height | 6 feet 7 inches. / 1.99 meters |
Machine length | 16 ft. 5 in. / 5 m |
Machine width | 2 feet 7 inches. / 0.79 meters |
Outrigger footprint length | 10 feet 7 inches. / 3.23 meters |
Outrigger coverage width | 10 feet 7 inches. / 3.23 meters |
Platform Dimension A | 4 feet 10 inches. / 1.47 meters |
Platform size B | 2 feet 6 inches. / 0.76 meters |
Track length | 4 feet 10 inches. / 1.47 meters |
Meet the specifications | |
Horizontal expansion | 30 feet / 9.14 meters |
Platform height | 59 ft. 3 in. / 18.06 m |
generally | |
Maximum ground pressure | 9.3 lbs/in² / 0.65 kg/cm² |
Ground bearing pressure - outriggers | 44.1 lbs/in² / 3.09 kg/cm² |
Machine weight | 6571 lbs / 2980.56 kg |
