| Battery | 8 x 6V, 370 amp hours |
| charger | 21 amp automatic thyristor rectifier |
| power supply | |
| brake | Spring applied hydraulics. Issued by CD |
| Capacity - Hydraulic oil tank | 8.5 gal. / 32.18 liters |
| Maximum ground pressure | 57 psi / 3.99 kg/cm2 |
| Hydraulic pump | Single stage gear pump |
| Machine weight | 9760 lbs / 4427.06 kg |
| generally | |
| Travel Speed - Platform Raised | 0.4 mph / 0.64 km/h |
| Drive Speed - Platform Lowered | 3 mph / 4.83 km/h |
| Gradeability - 2WD | 35 % |
| Gradeability - 4WD | 45 % |
| Lifting time | 38 seconds. |
| Lower time | 42 seconds. |
| Maximum driving height | 33 feet / 10.06 meters |
| Maximum lifting height | 33 feet / 10.06 meters |
| Platform capacity | 1000 lbs / 453.59 kg |
| Platform Capacity - Expansion | 250 lbs / 113.40 kg |
| Turning Radius - Outside | 15 ft. 6 in. / 4.72 m |
| performance | |
| Distance from the ground | 8 in. / 0.2 m |
| Machine height | 9 feet / 2.74 meters |
| Machine height - rails folded | 6 feet 5 inches. / 1.96 meters |
| Machine length | 10 ft. 4 in. / 3.15 m |
| Machine width | 5 feet 9 inches. / 1.75 meters |
| Platform Dimension A | 9 feet 7 inches. / 2.92 meters |
| Platform size B | 5 feet 5 inches. / 1.65 meters |
| Platform extension length | 3 feet / 0.91 meters |
| Platform height - lowered | 5 feet 7 inches. / 1.69 meters |
| Platform railing height | 3 feet 8 inches. / 1.1 meters |
| Tire size | 240/55 x 17.5 unmarked |
| Wheelbase | 7 feet 7 inches. / 2.3 meters |
| Number of sizes | |
| Platform height | 33 feet / 10.06 meters |
| Working height |
39 feet / 11.89 meters |
| Meet the specifications | |
