power supply | |
Battery | 8 x 6V, 370 Amp-hour |
charger | 21 amp automatic thyristor rectifier |
generally | |
brake | Spring applied hydraulic release plate |
Capacity - Hydraulic oil tank | 8.5 gal. / 32.18 liters |
Maximum ground pressure | 61 psi / 4.27 kg/cm2 |
Hydraulic pump | Single stage gear pump |
Machine weight | 10560 lbs / 4789.94 kg |
Performance | |
Travel Speed - Platform Raised | 0.4 mph / 0.64 km/h |
Drive Speed - Platform Lowered | 3 mph / 4.83 km/h |
Gradeability - 2WD | 35 % |
Gradeability - 4WD | 45 % |
Lifting time | 54 seconds. |
Lower time | 50 seconds. |
Maximum driving height | 30 feet / 9.14 meters |
Maximum lifting height | 40 feet / 12.19 meters |
Outriggers or Stabilizers | No |
Platform capacity | 800 lbs / 362.87 kg |
Platform Capacity - Expansion | 250 lbs / 113.40 kg |
Turning Radius - Outside | 15 ft. 6 in. / 4.72 m |
Number of sizes | |
Distance from the ground | 8 in. / 0.2 m |
Machine height | 9 feet 3 inches. / 2.81 meters |
Machine height - rails folded | 6 feet 7 inches. / 2.01 meters |
Machine length | 10 ft. 4 in. / 3.15 m |
Machine width | 5 feet 9 inches. / 1.75 meters |
Platform Dimension A | 9 feet 7 inches. / 2.92 meters |
Platform size B | 5 feet 5 inches. / 1.65 meters |
Platform extension length | 3 feet / 0.91 meters |
Platform height - lowered | 5 feet 9 inches. / 1.75 meters |
Platform railing height | 3 feet 8 inches. / 1.1 meters |
Tire size | 240/55 x 17.5 unmarked |
Wheelbase | 7 feet 7 inches. / 2.3 meters |
Meet the specifications | |
Platform height | 40 feet / 12.19 meters |
Working height |
46 feet / 14.02 meters |
