3246ES

● Platform height: 9.68 meters ● Machine width: 1.17 meters ● Working height: 10.7 meters ● Quieter cleaner operation for a variety of environments. ● Electric drive and integrated components with only two hydraulic hoses and four hydraulic fittings throughout the machine will keep you working longer and reduce operating costs by reducing the chance of leaks and service calls. ● Small turning radius and strong maneuverability.

Products Details
power supply
Battery 4 x 6V, 220 Amp-hour
charger 20 amp automatic

generally
brake Electric, Friction
Capacity - Hydraulic oil tank 1.7 gal. / 6.44 liters
Maximum ground pressure 87 psi / 6.09 kg/cm2
Hydraulic pump Fixed displacement gear
Machine weight 4975 lbs / 2256.62 kg

Performance
Turning Radius - Inside 0 in. / 0 m
Travel Speed ​​- Platform Raised 0.5 mph / 0.80 km/h
Drive Speed ​​- Platform Lowered 2.5 mph / 4.02 km/h
Gradeability 25 %
Lifting time 55 seconds.
Lower time 62 seconds.
Maximum driving height 31 ft. 9 in. / 9.68 m
Maximum lifting height 31.8 ft / 9.68 m
Platform Capacity - Expansion 250 lbs / 113.40 kg
Platform capacity is limited 1000 lbs / 453.59 kg
Platform capacity - unlimited 700 lbs / 317.51 ​​kg
Turning Radius - Outside 7 feet 11 inches. / 2.42 meters

Number of sizes
Distance from the ground 5 in. / 0.13 m
Machine height 7 feet 9 inches. / 2.36 meters
Machine height - rails folded 6 feet 6 inches. / 1.97 meters
Machine length 8 ft. 3 in. / 2.5 m
Machine width 3 feet 10 inches. / 1.17 meters
Platform Dimension A 8 ft. 3 in. / 2.5 m
Platform size B 3 feet 8 inches. / 1.12 meters
Platform extension length 4 feet 2 inches. / 1.27 meters
Platform height - lowered 4 feet 2 inches. / 1.26 meters
Platform railing height 3 feet 7 inches. / 1.1 meters
Tire size 16 x 5 in.
Wheelbase 6 feet 10 inches. / 2.08 meters

Meet the specifications
Platform height 31 ft. 9 in. / 9.68 m
Working height 37 ft. 9 in. / 11.51 m
