| Battery | 24 volts - 240 amp hours |
| Electrical System | 24 Volts DC |
| power supply | |
| Travel Speed - Platform Lowered | 5.50 km/h / 3.4 mph |
| Gradeability - 2WD | 25 % |
| Platform load | 200 kg / 440.9 lb |
| Turntable rotation | 345 Degrees |
| Rotation type | Discontinuous |
| Turning Radius - Outside | 1.99 m / 6.5 ft |
| Vertical Jib Rotation | 127 Degrees |
| Performance Parameters | |
| Ground clearance | 0.11 m / 4 in. |
| Machine height | 1.99 m / 6.5 ft |
| Machine length | 2.82 m / 9.3 ft |
| Machine width | 0.99 m / 3.2 ft |
| Platform size A | 0.90 m / 3 ft |
| Platform size B | 0.70 m / 2.3 ft |
| Platform height | 8.10 m / 26.6 ft |
| Drift | 0.13 m / 5 in. |
| Wheelbase | 1.20 m / 3.9 ft |
| Dimensions | |
| Horizontal jib rotation | 0 Degrees |
| Horizontal reach | 3.08 m / 10.1 ft |
| Platform height | 8.10 m / 26.6 ft |
| Crossing height | 6.51 m / 21.4 ft |
| Reach Specifications | |
| Capacity - Hydraulic oil tank | 9 L / 2.4 gal. |
| Vehicle weight |
2990 kg / 6591.8 lb |
| Basic Specifications | |
