power supply | |
auxiliary power | 12 Volts DC |
Capacity - Fuel tank | 117 L / 30.9 gal. |
Engine Type - Diesel - LRC | Deutz TD2011L4 55.9 kW 74.9 HP |
Performance Parameters | |
Shaft swing balance | 0.3 m / 1 ft |
Travel speed - 4 wheel drive | 5.20 km/h / 3.2 mph |
Gradeability - 4WD | 45% |
Platform load - limited | 450 kg / 992.1 lb |
Platform load - unlimited | 230kg/507.1lb |
Turntable rotation | 360 Degrees |
Rotation type | continuous |
Turning Radius - Outside (Axle Extended) | 5.89 m / 19.3 ft |
Turning Radius - Outside (Axle Retracted) | 6.86 m / 22.5 ft |
Vertical Jib Rotation | 130 Degrees |
Dimensional data | |
high | 11.86 m / 38.9 ft |
Ground clearance | 0.3 m / 1 ft |
Machine height | 3.05 m / 10 ft |
Machine length | 14.89 m / 48.9 ft |
Machine width | 2.49 m / 8.2 ft |
internal width | 3.81 m / 12.5 ft |
Platform size A | 0.91 m / 3 ft |
Platform size B | 2.44m/8ft |
Platform height | 41.30 m / 135.5 ft |
flick | 1.68 m / 5.5 ft |
Tire size | 445/50D710 foam filling |
Reach Specifications | |
Working height | 43.30 m / 142.1 ft |
Horizontal jib rotation | 180 Degrees |
Horizontal reach | 24.38 m / 80 ft |
Platform height | 41.30 m / 135.5 ft |
Basic specifications | |
Capacity - Hydraulic oil tank | 250 L / 66 gal. |
Deadweight | 7.52 Kg/cm2 |
Vehicle weight | 20411 kg / 44998.6 lb |
