Battery | 4 x 6V 220 amp hours |
charger | 27A General Algorithm |
power supply |
brake | Multi-disc friction |
Capacity - Hydraulic oil tank | 4.5 gal. / 17.03 liters |
Maximum ground pressure | 101 psi / 7.07 kg/cm2 |
Hydraulic pump | Fixed displacement gear |
Machine weight | 2630 lbs / 1192.95 kg |
generally |
Travel Speed - Platform Raised | 0.5 mph / 0.80 km/h |
Drive Speed - Platform Lowered | 2 mph / 3.22 km/h |
Drivetrain | Hydraulic front wheel |
Gradeability | 25 % |
Lifting time | 25 seconds. |
Lower time | 26 seconds. |
Maximum driving height | 19 feet / 5.79 meters |
Platform Capacity - Expansion | 250 lbs / 113.40 kg |
Platform capacity - unlimited | 550 lbs / 249.48 kg |
Turning Radius - Inside | 0 in. / 0 m |
Turning Radius - Outside | 5 feet 6 inches. / 1.68 meters |
Performance |
Distance from the ground | 3 in. / 0.07 m |
Machine height | 6 feet 7 inches. / 1.99 meters |
Machine length | 5 feet 9 inches. / 1.74 meters |
Machine width | 2 feet 8 inches. / 0.81 meters |
Platform extension length | 3 feet / 0.91 meters |
Platform height - lowered | 3 feet 3 inches. / 0.98 meters |
Platform railing height | 3 feet 4 inches. / 1.01 meters |
Platform size | 25.4in x 62.7in |
Tire size | 12 x 4 inches |
Wheelbase | 4 feet 5 inches. / 1.35 meters |
Number of sizes |
Platform height | 19 feet / 5.79 meters |
Working height | 25 feet / 7.62 meters |
Meet the specifications |
