Battery | 4 x 6V 220 Amp-hour |
charger | 27 amp high frequency charger |
power supply |
brake | Multi-disc friction |
Capacity - Hydraulic oil tank | 4 gal. / 15.14 liters |
Hydraulic pump | Fixed displacement gear |
Machine weight | 4310 lbs / 1954.98 kg |
generally |
Travel Speed - Platform Raised | 0.5 mph / 0.80 km/h |
Drive Speed - Platform Lowered | 2 mph / 3.22 km/h |
Drivetrain | Hydraulic front wheel |
Gradeability | 25 % |
Lifting time | 56 seconds. |
Lower time | 42 seconds. |
Maximum driving height | 25 ft. 6 in. / 7.77 m |
Platform Capacity - Expansion | 265 lbs / 120.20 kg |
Platform Capacity - Indoor | 507 lbs / 229.97 kg |
Platform Capacity - Outdoor | 275 lbs / 124.74 kg |
Turning Radius - Inside | 0 in. / 0 m |
Turning Radius - Outside | 7 feet 4 inches. / 2.24 meters |
Performance |
Distance from the ground | 4 in. / 0.1 m |
Machine height - rails folded | 5 feet 10 inches. / 1.79 meters |
Machine length | 7 feet 10 inches. / 2.4 meters |
Machine width | 2 feet 8 inches. / 0.81 meters |
Platform extension length | 2 feet 10 inches. / 0.86 meters |
Platform height - lowered | 3 feet 8 inches. / 1.11 meters |
Platform railing height | 3 feet 9 inches. / 1.13 meters |
Platform size | 25.4 x 84in |
Tire size | 16 x 5 inches unmarked |
Wheelbase | 6 feet 2 inches. / 1.88 meters |
Number of sizes |
Platform height | 25 ft. 6 in. / 7.77 m |
Working height |
31 ft. 6 in. / 9.6 m |
